23cm Projekten - Antenne's

Klik voor vergroting23cm Antenna by OK1AYU
I have built this "junkbox" antenna for my first tests on 23cm with the packet node OK0NJ. The original article was published in the Slovak HAM radio magazine Radiozurnal 1/1998. The antenna on this drawing is horizontally polarized. If you need vertical polarization, just turn it 90 degrees.
http://www.qsl.net/ok1ayu/projects/ant23.htm

Klik voor vergrotingA 23 elements 23cm yagi antenna by PA4DAN
I have been looking around for antennas for a while for 23cm ATV reception. The design of the antenna is very straight forward. It's a boom made of aluminium with the elements 'floating' above it on plastic isolators.
http://pa4dan.nl/ham/homebrew/23cm_beam/index.html

Klik voor vergrotingA Double Quad Antenna for 1296 MHz by DL5NEG
This antenna is a medium gain directional antenna for mobile (portable) and base station use. I have built it many years ago for mobile operation to check out how good the signal of the ATV Relais DB0SCS is received ...
http://www.herbert-dingfelder.de/?page_id=353

Klik voor vergrotingA quad stacked double-quad by PA4DAN
A while ago I tried to receive ATV-signals with a single double-quad antenna. The antenna performed very good compared to a simple groundplane antenna. But signals were still too weak to really make a picture out of it, so I started experimenting with stacking more than one double-quad to get a higher gain.
http://pa4dan.nl/ham/homebrew/antennas/23cm_qsq.html

Klik voor vergrotingAlford slot antenne voor 23 en 13 cm band door PA3CRX
Deze antenne is een horizontaal gepolariseerde rondstraler. De gain is niet erg groot (de 13 cm versie is gemeten in 2010 door de afdeling Meppel van de Veron met 2,35 dBi). Het stralingsdiagram is bijna rond, met een voorkeurdrichting aan de kant van de sleuf. Of de antenne naast de mast is geplaatst of er boven uit steekt bleek niet uit te maken.
https://www.pi6ats.nl/alfordslot.htm

An Inexpensive External GPS Antenna by N7KKQ
If you operate APRS or just need an external antenna for your GPS receiver, here’s one that is easy to build yet offers surprisingly good performance in a compact size. ..., it uses commonly available components and materials.
http://www.arrl.org/files/file/Technology/tis/info/pdf/0210036.pdf

Klik voor vergrotingCircular-waveguide horn for 23cm by S53MV
Various-size coffee cans usually make useful linearly-polarized horns for 1.7GHz and 2.4GHz. A weatherproof waveguide horn for 1.3GHz (23cm) is a little bit too large for practical cans and will probably have to be purpose-built from aluminum sheet.
http://lea.hamradio.si/~s53mv/wumca/horn.html

Klik voor vergrotingDevelopment of a 23cm patch antenna by G6GVI
Looking for a robust design for a portable antenna to use with my new DJ-G7E, I decided to try a microstrip patch. This is just a precisely-shaped conductive plate suspended above a ground-plane; but by using PCB techniques, this becomes a simple rectangular "flat-panel" antenna.
https://www.qsl.net/g6gvi/23cmpatch.html

Klik voor vergrotingDoppelquad antennes voor de 24 cm. band door PI6ATC
Als eenvoudige beginnersantenne of voor iemand die voldoende sterke signalen kan ontvangen is de dubbelquad (in het Duits 'Doppelquad') geschikt. De openingshoek is royaal genoeg om 'globaal' uit te richten.
https://www.pi6ats.nl/doppelquad.htm

Klik voor vergrotingDubbel acht antenne voor 23 cm. door PI6ATC
Bij een dubbel acht antenne (in het Duits 'Doppel Acht') wordt het concept van de doppelquad verder doorgevoerd: in plaats van de quad elementen tegenover het voedingspunt te sluiten worden ook hier quad elementen (in tegenfase) aangesloten.
https://www.pi6ats.nl/doppelacht.htm

Klik voor vergrotingHB9CV Antenne für 23cm by DH2PA
Um einen im Aufbau befindlichen 23cm Transverter zu testen, benötigte ich eine kleine, leichte Antenne, die ohne Halterung, nur durch das Semi-Rigid am Transverter befestigt werden kann.
http://www.dh2pa.darc.de/hb9cv23.html

Klik voor vergrotingHB9CV-in-a-box antenna for 23cm by PA3HCM
The HB9CV has been a popular antenna for decades, especially on the 2m band where it is commonly used for direction finding (foxhunt). Others create arrays of HB9CV antennas for DXing. Since I needed a simple antenna for 23cm (to uplink to the local ATV repeater PI6ATV) I thought it would be nice to use this HB9CV design.
http://www.pa3hcm.nl/?p=450

Klik voor vergrotingJednoduchá anténa OK2KKW pro pásmo 1296 MHz napsáno OK1VPZ
Tuto anténu jsme vyvinuli za přispění OK1ANQ již v roce 1996. Účelem bylo vyvinout anténu, která by se dala používat na pracovišti 23 cm během závodů v případě, že by byla upevněna na stejném stožáru jako 70 cm.
http://www.ok2kkw.com/antena23cm.htm

Klik voor vergrotingLog periodic Antenna voor 23, 13 en 9 cm. door PI6ATC
De LPA is gebouwd overeenkomstig een ontwerp van DC8CE. Als materiaal voor de open lijn (de 'dubbele boom') is 6 mm rond buismateriaal gebruikt.
https://www.pi6ats.nl/lpd%20design.htm

Klik voor vergrotingParabolic Dish Ring Feed by DL4MEA
For illuminating a parabolic dish with small f/D (around 0.4, not critical) a ring feed can be used. Its advantages are a wide illumination in both axis' without a large shadowing of the dish. It offers linear polarisation.
http://www.qsl.net/dl4mea/ringfeed.htm

Quick and Cheap Omni Antenna for 1296 MHz by W1GHZ
The sketch in the article has dimensions for 1.7 GHz and uses 0.086 inch semi-rigid coax. I scaled the dimensions to 1296 MHz and found a piece of 0.141 inch semi-rigid coax with an SMA connector on one end.
http://www.w1ghz.org/small_proj/Omni_Antenna_for_1296_MHz.pdf

Klik voor vergrotingShort DL6WU yagi for 23cm by PA3HCM
In the previous Winter I built a HB9CV-in-a-box for 23cm for my uplink to the local ATV repeater PI6ATV. Although this antenna works nicely, its gain just isn’t enough when their 23cm preamp is broken (which, unfortunately, is the case most of the time). To achieve a more steady uplink, I decided to build an antenna with a bit more gain, at least 6 dB extra compared to the HB9CV. A short yagi should make this possible.
http://www.pa3hcm.nl/?p=650

Klik voor vergrotingTri-Band Ring-straaler door PE1RKM
Ik heb in 2005 een nieuwe mast geplaatst. Ik wou hierin een antenne plaatsen, waarmee ik zoveel mogelijk SHF banden mee kan bestrijken, en niet onbelangrijk met ook nog een goede versterking.
https://pi6anh.com/?cat=11
